victor emergency
Emergency Safety light for industrial facilities
Reliable emergency light to ensure safe conditions in case of power failure.
- Available in different versions:
- Central battery system 230 V AC/DC
- Addressed central battery system CPS 100
- Addressed central battery system, Teknoware
- Self-contained with 1h/3h lithium-ion battery (LiFePO4), with automatic self-test function
- Self-contained, connectable to CPS300 addressed central
- Light source LED 10W
- Housing in extruded aluminium, end caps in die cast aluminium
- Silicone gaskets, integrated particle filter
- Diffuser in tempered safety glass (optional diffuser in PMMA or PC), diffuser frame in extruded aluminium
- Diffuser hinged to the housing, hinges in aluminium
- Connection -0- 5×2,5mm² 2xM25 cable glands
- Electrical class I
- Protection rating IP64
Versions and product codes
|
Product code |
Total power |
Net flux |
Connection |
Voltage |
Version |
Addressed |
Ta |
Kg |
|
LED T 23 D1 |
10W |
1800 lm |
-0- 5x2,5mm² |
230V AC/DC |
Central battery |
No |
-30…+40°C |
3,0 |
|
LED T 23 D5 |
12W |
1800 lm |
-0- 5x2,5mm² |
230 V AC |
CPS100-central battery |
Yes |
-30…+40°C |
3,2 |
|
LED T 23 D7 |
12W |
1800 lm |
-0- 5x2,5mm² |
230V AC/DC |
Teknoware central battery |
Yes |
-25…+40°C |
3,2 |
|
LED T 25 D1 |
5W |
800 lm |
-0- 5x2,5mm² |
230V AC |
Self-contained with battery 1h/3h |
No |
5…+40°C |
3,5 |
|
LED T 25 D9 |
4W |
800 lm |
-0- 5x2,5mm² |
230V AC |
Self-contained with battery 1h/3h, connectable to CPS300 central |
Yes |
-30…+40°C |
3,5 |
Options:
|
Option |
Extra code at the end of the product code |
|
Polyester coating, standard color RAL 7024 |
EP |
|
Diffuser in PC |
PC |
|
Diffuser in PMMA |
PM |
Download:
VictorEmergency-042022 (datasheet, pdf)
